鋼木結構實驗臺

更新：2017/7/20 16:59:44??????點擊：

品牌：???上海飛宇
型號：???Steel wood

產品介紹

Cabinet body :

Side plate, roof plate, baffle, and bottom plate of base box: made of 15mm thick environmental-friendly boards;

Top plate of base box and drawer : made of 15mm thick MDF;

Side plate of drawer and rear maintenance plate: made of 15mm thick environmental-friendly MDF;

Bottom plate of drawer : made of 10mm thick environmental-friendly MDF;

Edge plate: made of 1.0mm PVC;

Edge sealing material for top plate of drawer and door : 2.0mm PVC.

柜體部分：

基箱側板、上頂板、隔板、底板：采用15mm厚的環保中纖板加工制作；

基箱面板、抽屜面板：采用15mm厚的中纖板加工制作；

抽屜側板、后維修板：采用15mm厚的環保中纖板加工制作；

抽屜底板：采用10mm厚的環保中纖板加工制作；

封邊：基箱板材封邊均為1.0mm的PVC封邊；

抽屜面板、門面板的封邊材料：為2.0mmPVC封邊。

Platform top:

Steel wooden central experimental platform can use solid boards and top boards (epoxy resin board, phenolic resin board, granite, stainless steel, ceramic, etc.) with color of black and offwhite.

臺面部分：

鋼木中央實驗臺面可采用實芯板、貼面板（環氧樹脂板、酚醛樹脂板、花崗巖、不銹鋼臺面、陶瓷等，可供選擇）；顏色有黑色、灰白色可供客戶選擇。

Frame:

Steel support uses 40*60 cold rolled rectangular steel pipe, supporting column uses the same size steel pipe with two sides welded with cold rolled U-steel, the surface is plated with color zinc for rust prevention and spray epoxy resin after acid washing, phosphatization and electrostatic powder by carbon dioxide arc welding to make acid-alkali resistant surface. The adhesion of protective layer meets the requirements of drop impact test and static load bearing＞250kg. Supporting column can be directly hung beside the cabinet without damaging the wall.

框架：

鋼支架采用40*60的冷軋矩形鋼管，支撐立柱為同規格鋼管兩面組焊鑲嵌冷軋槽鋼，表面電鍍彩鋅作防銹預處理，經二氧化碳冷焊組合后再酸洗、磷化并靜電粉沫噴涂環氧化樹脂防護層作耐酸堿耐腐蝕表面處理，其保護層附著力經落物撞擊測試合格，靜態承重＞250公斤，支撐立柱可直接懸掛呆柜，無須破壞墻身。
